Maxge E50-18DPOS4G 180 kW DC EV Charger

The Maxge E50 is a DC fast-charging station from the E50 series, which is offered in 60, 90, 120, 150, 180 and 240 kW versions. It supports a DC charging voltage range of 200 to 1,000 V and has two CCS2 connectors. A single vehicle can receive full station power, or the power can be shared between two vehicles at once through load balancing.

The series has a compact design with no rear ventilation openings, so it can be installed against a wall or back to back. Connectivity includes Ethernet and WiFi, with optional 4G. Users can authenticate by RFID, QR code, password or an OCPP-compatible app, and an optional POS payment terminal can be fitted. The series includes dynamic power management and load balancing, emergency stop, CE certification, and protection against overvoltage, undervoltage, overload, short circuit, residual current, earth faults and overtemperature. The published series data gives an IP55 and IK10 rating, and lists CAN, RS485 and RS232 interfaces for monitoring and energy management integration.

Data sources describe the E50 series as a whole. Model-specific details for the E50-18DPOS4G, including AC input power, dimensions and weight, were not found in these sources.
